The Introduction of symons cone crusher
The hammer crusher is a kind of equipment for crushing materials in the form of impact, which is divided into two types: single rotor and double rotor..
The Introduction of symons cone crusher
The hammer crusher is a kind of equipment for crushing materials in the form of impact, which is divided into two types: single rotor and double rotor. It is a section of crushing crusher that directly crushes materials with a maximum particle size of 600-1800 mm to 25 or less. Hammer crusher is suitable for crushing medium-hard materials such as limestone, slag, coke, coal and other materials in cement, chemical, electric power, metallurgical and other industrial sectors. The crushed materials are coal, salt, chalk, gypsum, brick, limestone and the like. It is also used to crush waste of wood, paper and broken asbestos cement with strong fiber structure, elasticity and toughness to recover asbestos fiber and so on. In addition, the hammer crusher can be used not only for crushing production lines, sand production lines, but also for conical crushers in beneficiation production lines.
Impact plate
Crusher Hammer
Consignment
1.Higher rotating speed and stroke make production capacity which improved 35%-60%.
2.Better finished product shape.
3.Hydraulic protection and hydraulic cavity clearing, high automatization and less stopping production and repairing time.
4.Thin oil lubrication makes the life time increased.
5.Hydraulic motor makes the adjustment of discharging opening size and replacement of wear parts more convient.
The Working prinpicle of symons cone crusher
The hammer crusher mainly relies on the impact energy to complete the crushing material operation. When the hammer crusher is working, the motor drives the rotor to rotate at a high speed, and the material enters the crusher cavity evenly. The high-speed rotary hammer impacts and shears the torn material, causing the material to be broken. At the same time, the gravity of the material itself causes the material to The high-speed rotating hammer head rushes toward the baffle and the screen strip in the frame body. The material larger than the size of the mesh hole is retained on the sieve plate and continues to be struck and ground by the hammer until it is broken to the required discharge particle size and finally discharged through the sieve plate. .
Model |
Capacity(tph) |
Feed opening (mm) |
Rotating speed (r/min) |
Motor power (kW) |
Overall dimensions (mm) |
<30mm |
<70mm |
HYPCD1416 |
200 |
280 |
≤600 |
500 |
200-4 |
1000-1600 |
HYPCD1616 |
280 |
400 |
≤700 |
420 |
200-4 |
1200-1600 |
HYPCD1620 |
380 |
530 |
≤700 |
420 |
250-4 |
1200-200 |
HYPCD1820 |
500 |
700 |
≤700 |
350 |
355-6 |
160-200 |
HYPCD2022 |
600 |
860 |
≤1000 |
350 |
500-6 |
2000-220 |
HYPCD2024 |
800 |
1100 |
≤1100 |
350 |
630-6 |
2000-2400 |
HYPCD2026 |
1000 |
1400 |
≤1100 |
350 |
710-6 |
2000-2600 |
HYPCD2426 |
1500 |
2100 |
≤1100 |
300 |
900-6 |
2400-2600 |
